Restoring a Thomson SkyHD box

I’ve been meaning too document the HD era of Sky for some time now and whilst I do have a HD Sky box (the DRX595), I’m interested in the early era of SkyHD.

The HD EPG has been through multiple iterations, first it launched with an upscaled version of the Sky Guide interface that graced many Digibox’s since 1998. Sky redesigned the EPG exclusively for the HD boxes in 2008, which is the EPG I’m currently interested in below, unfortunately the majority of all HD boxes run newer versions of Sky HD guide, all except for one

Thomson DS8215

Thomson DSI8215

This was the launch STB for Sky HD, and remained the only box until 2008 when Sky started sourcing from Pace, Amstrad and Samsung, and were the only boxes that had analogue HD outputs (Component/YPbPr). Whilst the other boxes continued to receive updates after 2011, Sky began to phase out the Thomson models, which remained on the 8.3.2 EPG, and was the last OpenTV based EPG.

Admittedly Thomson were not the best manufacturer of Sky digibox’s. Don’t get me wrong, they’re mostly fine but nearly all Thomson (and Grundig, more on that later) digibox fall suspect of faulty PSU capacitors, which can cause myriad of issues from being stuck in standby to no satellite signal, and the HD box was sadly no exception to this.

First Impression

The box seemed to have been in use for a few years, and has had a bit of wear and tear.

Well it looks OK so far…

Seems to have had a lot of dust and grime build up over the past few years from the previous owner

The hard drive seems to have taken the brunt of it all, since there is a fan situated right below it that serves as the air intake.

Yeesh…

At this point I figured I had to take the box outside and clean it with a can of compressed air to get the dirt out.

Power Supply

A common issue on Thomson SkyHD (and Sky+/Digibox’s) is the power supply capacitors failing, all thanks to capacitor plague. This isn’t unique to Thomson Sky boxes as it can affect Grundig models as well, Thankfully it’s fixable even in 2021 either by yourself or you can send it off to be repaired. You can see in the above picture that one of the capacitors has started leaking, whilst others are bulging slightly.

This can also affect other consumer electronics from the 1999-2006 era, notably the clock capacitor on the original Xbox and various PC motherboards.

This box specifically had issues finding a satellite signal, and would only display ‘no Satellite signal is being received’ on both tuners, respective of either single or dual feed being used. Also a audible whine could be heard from the power supply, which is usually not a good sign.

The replaced capacitors

Conclusion

its worth mentioning that Sky no longer support this box for HD channels, whilst SD subscription channels and HD Free-To-Air channels will work, HD subscription channels will not work, since Sky moved to a different card pairing method this this box does not support, still for Freesat or basic subscription use the box will continue to work. The box also does not support any catch-up or On demand services offered by Sky.

One thing to mention with this box is it will no longer recognize any viewing cards, this is probably due to fault with the box, either the card reader has failed or the contacts are dirty. This makes it impossible to use it with Sky+ modes since they require a Sky+ reenabled viewing card to work.

With this in mind I may decide to change the hard drive for a dummy Sata-SD card adaptor, since it makes no since having a hard drive that wont be used. I’m not sure what HDD space requirements the box has, since the box likes to reserve 140Gb for Anytime use.

Size Comparison

The Thomson SkyHD box was quite large compared to the previous set top boxes Sky have deployed, lets see how it compares:

Vs Xbox

Vs ntl: box

Vs Pace Digibox

Vs Virgin Media Tivo

Sky Interactive – 2001

A look at Sky’s interactive services offered from 2001

Sky Text

Sky Text

An alternative interactive service provided by Sky, unlike Active that facoused on shopping and games, Text focused on information like local listings, news, weather, etc

Open....

Open…

Prior to its relaunch to Sky Active in late 2001. Open… was the main interactive portal on Sky Digital, and provided a gateway to other interactive services

Open....

Open… Shopping

E-commerce was the main attration of interactive TV, with the ability to buy products though Sky Digital

Woolworths

Woolworths

Woolworth (Remember them?) was one such retailer

Sky Text

Sky Text

Sky text was designed to be used whilst watching regular Sky TV channels

Horoscopes

Not much to say, just star signs and horoscopes

Asda

Asda

Supermarket portal, do your grocery shopping through your TV

Harrods

Harrods

Simpsons Sky One

The Simpsons

Sky Movies Active

Sky Movies Active

Sky Cinema

Cinema Listings

Sky Guide 2002

Sky Guide Redesign

Sky were due to redesign the Sky Guide interface, with a new two tone blue interface in line with the corporate branding of the time.

BT Phone BIll

BT Phone

This never officially launched, but at some point you were supposed to be able to manage your phone bills via your TV, this would have extended to your Gas, Electric and Water

Domino's Pizza

Domino’s Pizza

Domino’s Pizza Prompt

Imperial Cancer Prompt

Imperial Cancer

Donate just by pressing your red button

Birds Eye Prompt

Birds Eye

Further Reading

PDF Download link

https://app.box.com/s/z3v1fgvh1xwf2y8kfw41aq9o6lixcloz

Using a Sony BRAVIA TV for Freesat

Many higher end Sony TV’s have had satellite tuners for a while now, and whilst you can easily connect it to a Sky dish and it’ll pick up and tune in channels, you will find that they are randomly allocated across the guide, which makes navigating them difficult. Compare this to similar Panasonic and Samsung TV’s that have proper official support for the Freesat EPG.

I decided to modify the EPG used by the TV in order to get it as close as I can to the Freesat order, allowing for a similar experience to an actual Freesat certified TV. This doesn’t fix the issue of lack of TV listings, since Freesat and Sky do not transmit their listings in the common DVB format so you will still be left with Now & Next only, you also won’t be able to decrypt the FTV channels, only view FTA channels that Freesat receivers can decode.

Whilst many Sony TV’s sold in the UK come with DVB-S2 compatible tuners, the issue is Freesat (and Sky) don’t use standard EIT (Event Information Table), which prevent these TV’s from being able to correctly manage these channels.

What You Need

USB Memory stick – Formatted to FAT32

Supported BRAVIA TV with a satellite tuner

Sony Channel Editor (Optional)

ChanSort (Recommended)

The Software

Sony Channel Editor

Sony Channel editor

I’m not gonna sugarcoat it, this software is garbage. Complete Garbage

Whilst it’s able to just do the bare minimum, its a horrible piece of software to navigate, and has a tendency to garble the interface if you select too many channels.

Sony channel editor
WTF?

I don’t get it, why is Sony incapable of producing software that is able to function property without glitching itself? Why did they feel the need to theme it all to hell and back, a simple Win32 application would have been more then welcome, but instead it has to be skinned. Just look at the open dialog

Why not just use the default Windows open dialog?

This is a frequent occurrence, Alt/tabbing sometimes fixes it, otherwise you will need to save and close.

This is also a pain, rearranging TV channels causes the software to get confused and plonks the channels out of order, see how it goes from 77 to 92, 93 and then back to 80

Chansort

After getting fed up with Sony’s software I instead opted for an alternative

Chansort Sony

Chansort is a channel list editing application designed for various TV and satellite receivers on the market. Simply open the sdb.xml extracted from your TV and away you go. This this it was easier to manage and reorganize the channel list to the Freesat order, rather than having channel spread across the EPG.

A common issue was when reordering the channel list with the Sony editor software, it would frequently push the channel list down, rather than replacing or swapping them. With Chansort, you can tell the software if you want to swap the channels, or just insert it before or after, whilst keeping the other channel intact. This became a huge problem with the Sony software as after organizing one section of the EPG, the rest would either shuffle out of their modified positions.

Testing

After making the changes I copied the xml file back to the memory stick and plugged it in the TV to import. After importing and letting the TV reboot, the custom channel list loaded.

Unfortunately I had then hit a snag, since the TV is set to automatically update the channel list, and because I had originally deleted the encrypted Sky channels of the guide, the TV decided to add the channels back into the EPG, and then decided to merge and slot them into the existing channel list, so whilst it kept my custom channel order (mostly), you ended up with a bunch of encrypted channels in between.

One solution to this was disabling the service update option, that would stop the TV from adding channels, but that would mean any new Freesat channels wouldn’t be picked up, also if a channel had changed transponders, then the TV would not pick up the new frequency, instead that channel would display a blank screen.

A workaround to this was to hide the channels instead of deleting them, so whilst the channels would still exist to the TV, they would be ignored. In addition I also moved the channels to the 1000+ section, so that in the event the TV does not hide the channels, they are out of the way from main view.

Considerations

  • Whilst the EPG now mirrors the Freesat guide, you still don’t get the full TV listings, rather the Now and Next data
  • When Sky/Astra add new channels, your TV will detect and will automatically add them to the guide, likewise if a channel changes frequency. You will then have to hide the channel, unless it’s a FTA channel that you want to view.
  • Regional channels, the BBC have multiple feeds for different regions, as do ITV for local news. Channel 4 also has different feeds for local advertising. These are all recognized by the TV as separate channels. Whilst the BBC channels are easy to figure out, since the region is in the channel name, ITV and channel 4 are more difficult, since they all have the same label (except for STV and UTV, although there are multiple STV regions) I ended up using the main London regions that a regular Sky box used if it had no viewing card inserted. Alternatively you could change the regions themselves using the same software I had used. Regardless I placed all regional channels in the 900 section, but they are not in a particular order.
  • Some channels are duplicated twice, like Challenge. This is due to Sky running different feeds for Sky and Freesat, maybe the Freesat versions have adverts targeting to resubscribing to Sky or NOWtv?
  • Some channels are FTA but they are not on Freesat, most of the music channels and many international non English channels, to solve this I allocated the 400 section for international channels since that range is vacant (not sure why Freesat has that empty?) music channel I used the old channel numbers, since many of them were on Freesat at some point
  • The Astra UHD test channels are assigned to 1-3, since they are interesting to view and many satellite Sony TV’s are 4K, 4-99 are vacant, My assumption is should the TV find new channels, they will be added here, making it easer to manage.
  • Also, when importing the satellite channel list, it will also replace the terrestrial Freeview channel list also. So after importing the channel list you may need to do a full rescan on the Freeview side unless your on the Sutton Coldfield transmitter. I’m currently looking at a way to remedy this

Download

SDB.xml – Contains the edit channel list that follows the Freesat line up

Download (Box)

Download (OneDrive)

Updated as of: March 2021

Importing (Export to TV)

  • Copy the sdb.xml file to a FAT32 formatted memory stick to the root of the drive (don’t place the file in any folders)
  • Insert the USB memory stick into the TV’s USB2 port
  • After a few seconds the TV should pop up with a message asking what to do with the memory stick, Select Cancel or Ignore
  • For newer models (Android 9), Press Home → Select Settings (Cog wheel) → Select Watch TV →  Select Channels  Program List Transfer →  Import
  • For older models (Android 8), Press Home → Select Settings→ Select Channel Setup →  [Digital setup] →  [Technical Set-up] →  [Program List Transfer] →  [Import]
  • The TV will then import the channel list and will then reboot

There are a few issues and inconsistences as outlined above, mostly with duplicated channels, and the auxiliary channels section being out of order (900+), hopefully the TV’s should have minimal issues with keeping the channels updated.
